805HP Hand Held Digital Indicator

· The ANYLOAD 805HP hand held digital indicator is a general purpose durable indicator and a force measurement device that provides high accuracy, reliability, and multiple functions. The 805HP can drive up to eight (8) 350Ω or thirty two (32) 1000Ω load cells with a Junction Box.  With an IP65 ABS wash down enclosure, the 805HP digital indicator is ideal for use in Transportation, Entertainment, Aerospace, Military, Food and Agricultural industry.

· Exceptionally long battery life: up to 1,600 hours with 3-AA batteries

· LED backlight and panoramic FSTN LCD view angle

· Material: ABS

· IP Rating: IP65

· LCD 6-digit display with LED backlight

· Non-volatile memory for reliable data saving

· Units of Measurement: kg, g, t, lb, Klb, N, kN, oz, user-defined unit

· Configurable 2 set-points for precaution and warning

· User-selectable display interval

· Overloading recording

· 10 user-selectable analog-to-digital converting frequency

· Weight calibration and digital calibration

· User-selectable auto power-off and power-saving timing

· Functions:Auto-Zero Tracking, Auto-Zero, Manual-Zero, Hold, Peak-Hold, TARE

805HP Handheld weighing display product datasheet download
