ANYLOAD Load Cell

  • 101AH-5kg load cell
101AH-5kg load cell

101AH-5kg load cell

  • Shape: S Type load cell
  • Material: Alloy Steel
  • Load direction:Compression & tention
  • Model:101AH-1kg 101AH-2kg 101AH-3kg 101AH-5kg 101AH-10kg 101AH-20kg 101AH-30kg
  • Product description: 101AH-5kg is a kind of universal material testing machine, which can be used either single or multiple at the same time. It is easy to install and debug. Application: Mechanical scale transformation (
  • INQUIRY

Chinese Shenzhen HNHT TECHNOLOGY Co., Ltd. 101AH-5kg is a rare weighing sensor. It has an excellent texture, a wide and plump layout, and a clean and crisp edge line. It reveals the excellent quality of the weighing sensor. Its stable performance, tension measurement and compression measurement are completed in one piece, making it one of the recommended multi-functional sensors.

Note: The following information is for reference, Please refer to ANYLOAD version

【Support services】
Warranty period: 12 months
Provide sensor technology support and selection recommendation
【ANYLOAD load cell 101AH-5kginformation】
ANYLOAD load cell 101AH-5kg is hot selling product in China, in stock,manufacturers supply, quality goods, after-sale protection. If you have any question, welcome to E-mail:sales@hnhtsz.com
ANYLOAD load cell 101AH-5kg datasheet download:


ANYLOAD load cell 101AH-5kg features

Material: Alloy steel

Rated Capacities: 1kg, 2kg, 3kg, 5kg, 10kg, 20kg, 30kg

Full Scale Output: 2mV/V ± 10%

Safe Overload: 150%

  Breaking Overload: 300%

IP Rating: IP65

CE, RoHS and Ex certified

Measurement Ukraine certified



ANYLOAD load cell 101AH-5kg dimension:

ANYLOAD load cell 101AH-5kg series models:

101AH-1kg  101AH-2kg  101AH-3kg  101AH-5kg  101AH-10kg  101AH-20kg  101AH-30kg



Shenzhen Huanan Hengtai Industrial Co.,Ltd supply 101AH-5kg  is the load cell adopts the elastic body as double-connected or sheared S-beam structure, compact structure, used for tensile force and compression force measurement, strong lateral force resistance, high precision, good symmetry of pull and pressure output, stable and reliable performance. Wide range of measuring range, easy to install and use, suitable for hook scales, belt scales, batching systems, packaging scales, electromechanical combination scales and special force measuring devices, hook scales, machine scales, hopper scales and other electronic weighing equipment .

If you want to know more about 101AH-5kg price, 101AH-5kg delivery time, 101AH-5kg manufacturer, 101AH-5kg product information, 101AH-5kg product specification, 101AH-5kg technical parameters, 101AH-5kg installation and debugging, 101AH-5kg wiring mode, please contact E-mail:sales@hnhtsz.com
