SUNCELLS Load Cell

SQB-A-1tLOAD CELL

Shape:single-ended Shear Beam
Material:alloy steel construction
Load direction：compression
Model:SQB-100kg,SQB-150kg,SQB-200kg,SQB-250kg,SQB-300kg,SQB-500kg,SQB-750kg,SQB-1t,SQB-1.5t,SQB-2t,SQB-2.5t,SQB-3t,SQB-5t,SQB-7.5t,SQB-10t,
Product description: SQB-A-1t is adopts cantilever beam structure and the force direction is pressure. It can be used with a single sensor or multiple sensors. It is easy to install and debug. It is used in weight measure
INQUIRY

Shenzhen Huanan Hengtai Industrial Co.,Ltd sale SQB-A-1t is a cantilever beam weighing sensor, internal filling sealant seal, oil proof, waterproof, corrosion resistance, can be applied to various environments, single shear beam structure design, easy to install and use flexible, suitable for electronic platform scale, hopper scale and other types of electronic weighing equipment.

【Support services】
Warranty period: 12 months
Provide sensor technology support and selection recommendation
【SUNCELLS LOAD CELL SQB-A-1t information】
SUNCELLS LOAD CELL SQB-A-1t is selling product in China, quality goods, after-sale protection. If you have any question, welcome to E-mail:sales@hnhtsz.com

Note: The following information is for reference, Please refer to SUNCELLS version
SUNCELLS LOAD CELL SQB-A-1t datasheet download：

SUNCELLS LOAD CELL SQB-A-1t features：
Internal glue sealing, oil proof, waterproof, corrosion resistant;
Single shear beam structure design, easy to install and use;
The output signal is not affected by the change of the bearing point;
Good linearity and high precision;
Simple structure, easy to seal, long-term stability, durable;
It is applied to the weight measurement of large tanks and hoppers, the measurement control of crane scales and automobile scales, to the batching system of mixing and distributing various raw materials, the automatic detection in the production process and the control of powder and particle feed quantity.

SUNCELLS LOAD CELL SQB-A-1t Applications：

SQB-A-1t is a high precision and cost-effective compression weighing solution, very suitable for a variety of applications, for pressure measurement, can be used with a single sensor, can also be used with multiple sensors, easy to install, debugging.

SUNCELLS LOAD CELL SQB-A-1t selection：

SUNCELLS LOAD CELL SQB-A-1t series models：

SQB-SS-100kg,SQB-SS-150kg,SQB-SS-200kg,SQB-SS-250kg,SQB-SS-300kg,SQB-SS-500kg,SQB-SS-750kg,SQB-SS-1t,SQB-SS-1.5t,SQB-SS-2t,SQB-SS-2.5t,SQB-SS-3t,SQB-SS-5t,SQB-SS-7.5t,SQB-SS-10t,

SQB-ASS-100kg,SQB-ASS-150kg,SQB-ASS-200kg,SQB-ASS-250kg,SQB-ASS-300kg,SQB-ASS-500kg,SQB-ASS-750kg,SQB-ASS-1t,SQB-ASS-1.5t,SQB-ASS-2t,SQB-ASS-2.5t,SQB-ASS-3t,SQB-ASS-5t,SQB-ASS-7.5t,SQB-ASS-10t,
