CELTRON LOAD CELL

STC-10kgAL load cell

Shape: S-type load cell
Nonlinearity: 0.02%±% of rated output(SS:0.05)
Load Direction:tension&compression
Model:STC-25kg STC-50kg STC-100kg STC-150KG STC-250kg STC-500kg STC-1T STC-2T STC-2.5T STC-5T
Product description: STC-10kgAL use for measuring tension or pressure, S shape, can be used alone, or can be output multiple at the same time through the assembly, used in mechanical reconstruction (machine to electricity
INQUIRY

China Shenzhen Huanan Hengtai Industrial Co.,Ltd sale STC-10kgAL is a stable performance, excellent material weighing sensor, to meet the public for tensile measurement, pressure measurement to complete the requirements and quality assurance, with the rapid development of industrialization, more and more modern use in different industrial environments show, and it is due to the sealing of thoughtful, to meet the needs of complex industrial environments to complete force measurement.

Inquiry for Quotation→E-mail:sales@hnhtsz.com

【Support services】
In stock, quality assurance, price concessions, fast delivery.
Warranty period: 12 months
Provide sensor technology support and selection recommendation

【VISHAY CELTRON load cell STC-10kgAL information】

Note: The following information is for reference, Please refer to VISHAY CELTRON version
VISHAY CELTRON load cell STC-10kgAL datasheet download：

VISHAY CELTRON load cell STC-10kgAL features：
Recommended excitation voltage :10V,AC/DC
Operating temperature range :-10℃~+40℃
Excitation voltage :15V,AC/DC
Temperature compensation range :-20℃~+60℃
Rated output :3mV/V±10%
Zero point balance :±1%
Creep error(20 minutes) :0.02%R.O
Input impedance: 385Ω±5Ω
Output impedance: 350Ω±3Ω
Insulation impedance gt:5000MΩ
Non-linearity :±0.02%R.O(SS:0.05)
Repeatability :±0.03%R.O
Safe load :150%
Failure load :300%
Moisture-proof rubber seal
Bidirectional (tension/compression)

VISHAY CELTRON load cell STC-10kgAL dimension：

VISHAY CELTRON load cell STC-10kgAL series models：

STC-10kgAL STC-5kgAL,STC-10kgAL
STC-25kg STC-50kg STC-100kg STC-150KG STC-250kg STC-500kg STC-1T STC-2T STC-2.5T STC-5T

If you want to know more about STC-10kgAL price, STC-10kgAL delivery time, STC-10kgAL manufacturer, STC-10kgAL product information, STC-10kgAL product specification,STC-10kgAL technical parameters, STC-10kgAL installation and debugging, STC-10kgAL wiring mode, please contact E-mail:sales@hnhtsz.com
