ANYLOAD Load Cell

108CA-20kg load cell

Shape:Single point type load cell
Material:Aluminum
Load direction：Widely used in compression
Model:108CA-10kg 108CA-20kg 108CA-30kg 108CA-60kg 108CA-100kg 108CA-150kg 108CA-200kg 108CA-250kg 108CA-300kg 108CA-500kg 108CA-600kg 108CA-750kg 108CA-1t
Product description: 108CA-20kg is a low-cost, high-precision sensor, which can be directly installed on the base of the scale or used in weighing and force measurement. It can be applied to the packaging scale, electroni
INQUIRY

Shenzhen Huanan Hengtai Industrial Co.,Ltd supply 108CA-20kg is a single point type low cross-section sensor. It is a cost-effective sensor designed to control the cost of weighing system. It has strong applicability, wide application, easy installation and easy use.

【Support services】
Warranty period: 12 months
Provide sensor technology support and selection recommendation
【ANYLOAD load cell 108CA-20kg information】
ANYLOAD load cell 108CA-20kg is hot selling product in China,quality goods, after-sale protection. If you have any question, welcome to E-mail:sales@hnhtsz.com
ANYLOAD load cell 108CA-20kg datasheet download：

ANYLOAD load cell 108CA-20kg features：

●Material: Aluminum

●Rated Capacities: 10kg, 20kg,30kg, 60kg, 100kg, 150kg, 200kg, 250kg, 300kg, 500kg, 600kg, 750kg, 1t

●Full Scale Output: 2mV/V ± 10%

●Safe Overload: 150%

●Breaking Overload: 300%

●IP Rating: IP66

●NTEP 1:4 000, Class III, Single Cell certified from 200kg-2t

●OIML C3, Y=4 300 certified from 10kg-500kg

●CE and RoHS certified

●Measurement Ukraine certified

●Measurement Spain certified
ANYLOAD load cell 108CA-20kg dimension：

ANYLOAD load cell 108CA-20kg series models：

108CA-10kg 108CA-20kg 108CA-30kg 108CA-60kg 108CA-100kg 108CA-150kg 108CA-200kg 108CA-250kg 108CA-300kg 108CA-500kg 108CA-600kg 108CA-750kg 108CA-1t

108CA-1000kg

Shenzhen Huanan Hengtai Industrial Co.,Ltd 108CA-20kgis a single point type low cross-section sensor. It is a cost-effective sensor designed to control the cost of weighing system. It has strong applicability, wide application, easy installation and easy use.

If you want to know more about 108CA-20kg price, 108CA-20kg delivery time, 108CA-20kg manufacturer, 108CA-20kg product information, 108CA-20kg product specification, 108CA-20kg technical parameters, 108CA-20kg installation and debugging, 108CA-20kg wiring mode, please contact E-mail:sales@hnhtsz.com
